Home » Products » Vegetable Process Machineries » Garlic Elevator Decorticator And Grader

Garlic Elevator Decorticator And Grader

Garlic Elevator Decorticator And Grader
Garlic Elevator Decorticator And Grader
Product Code : VPM 12
Product Description

Garlic Elevator Decorticator And Grader


INTRODUCTION :


This machine is special design for garlic process. It consisting of three units Elevator, Decorticator and Grader. First of all elevator continuously feeds material in decorticator, there garlic bulb brakes inside and take place through a screen and deposits in to grader, where each garlic segment divide into three grades and waste. This machine constructed from ms and GI material.





MACHINE TECHNICAL SPECIFICATION
NO SPECIFICATION MODEL- 0 MODEL-1 MODEL-2
1   CAPACITY KG/HR 200-300 Kg-Hr 750-1000 Kg-Hr 1500-2000 Kg-Hr
2   TOTAL POWER-HP 3.7 KW 6.75 KW 8.25 KW
3   WATER CONSUMPTION KG/HR NA NA NA
4   SIZE IN MM ELEV-300 X 2MT DECO-ROTAR DIA-500 GRADER- 300 X400 ELEV – 450 X 3 MTR DECO ROTAR DIA-750 GRADER- 1200 X 1800 ELEV – 500 X 6MTR DECO ROTAR- 900MM GRADER – 1200X2500
5   SPACE REQ- L X B X H – IN MTR  2.5 X 1 X 2 MTR 4 X 2 X 4 MTR 4 X 3 X 7 MTR
